Face Based Time Attendance System

Face Recognition Access Control System




VF380 is a face identification T&A terminal with simple access control functions, which can connect with 3rd party electric lock, door sensor, and exit button. Face, PIN & RFID recognition modes are available. VF380 captures the relative positio, size and shape of the user's eyes, nose, cheekbones and jaw features to ensure accuracy of the identification. All the settings can be easily done on 3 inch TFT touch screen. With a VF380 you can manage your workforce and access control efficiently.

Features

  • Elegant ergonomic design.
  • Ethernet & USB host communication.
  • 3 Inch TFT touch screen, T9 Input & 9 digit User ID.
  • Infra-red optical system enables user-identification in poorly lit environment.
  • Optional with Mifare card module.
  • Professional face identification algorithm.
  • 3rd party electric lock, door sensor and exit button.



Configuration



Technical Specification

Display 3 inch touch screen
Face capacity 200 (1:N)
ID card capacity 10,000
Logs capacity 100,000
Communication Ethernet & USB host
Optional function Mifare Card
Power supply 12 V/1.5A
Verification speed <1S
Operating temperature 0°C-45°C
Operating humidity 20% - 80%
Dimensions 104.70(L) x 180.00(H)x36.00(W)mm

Face cum Biomtric Fingerprint System

i-Face301(302) multi-biometric identification time attendance & access control terminal adopts ZKSoftware's latest platform with ZK face 7.0 algorithm and large capacity memory. iFace series integrated 800 MHz high speed ZK Multi-Bio processor & high definition infrared camera enables user identification in the dark enviornrment. Face and fingerprint multi biometric identification method will be applicable more widely. All operations of iFace are designed to be performed on the 4.3 inches TFT touch screen . Multi-model communications includes RS232/485, TCP/IP, optional Wi-Fi or GPRS . Optional built-in 2000 mAh battery eliminates the trouble of power -failure.

Features

  • Identification methods include Face, Fingerprint/RFID and /or Password
  • Elegant Ergonomic Design.
  • 4.3" TFT touch screen is user-friendly and very intuitive
  • 6 user -defined function keys.
  • Contact relays for door access control (wires to door strike or 3rd party panel)
  • Web server management s/w via IE browser
  • Optional extendable scheduled-bell
  • Infra-red optical system enables user -identification in poorly lit environments.
  • Optional built-in battery backup provides approx 4 hours continuous operation
  • Optional built-in wireless Wi-Fi or GPRS for wireless communication
  • Built-in contacts for 3rd party electric lock, door sensor, alarm, exit button, or bell.
  • Wiegand output for connections to 3rd party access control panels.
Configuration

Time Attendance System Suppliers

Technical Specification

iFace301 iFace302
CPU ZK Multi Bio CPU 800 Mhz
Memory 256M Flash, 64M SDRAM
H/w Plateform ZME 600 Multi Medium Development Platform
Fingerprint Sensor None ZK Optical Fingerprint Sensor without film
Camera High resolution infrared camera
Display 4.3" TFT touch screen
Face capacity 500(1:N) 500(1:N)
Fingerprint capacity None 2000
ID Card capacity 10,000 10,000
Logs Capacity 100,000 100,000
Algorith version ZK Face 7.0 ZK Face 7.0 & ZK Finger 10.0
2000mAH backup battery Optional Optional
Communication TCP/IP , RS232/485
USB Host Two USB Host
Wireless Wi-Fi Optional Optional
Time attendance standard functions ID card (302 Optional), Automatic Status Switch, Self-Service query, Work code, T9 Input, 9 digit user ID, DLST
Access control interfaces for 3rd party electric lock, door sensor, exit button 3rd party electric lock, door sensor, exit button
Weigand functions Output Output
Optional Functions Serial Printer, Mifare Card, Extendable Scheduled Bell, Short Message, Web-Server, GPRS
Power Supply 12V3A
Verification Speed <=2sec
Operating Temp 0°C-45°C
Operating Humidity 20%-80%
Dimension 193.6x146.8x111mm
Gross Weight 1.65kg 1.90kg
